Botheven Machinery

• Equipped Servo Motor for precise cutting length (±1%).

• Equipped high quality alloy steel cutter.

• Equipped bag mouth open device.

• Punching Unit for "X" Hole and "O" hole Punch available.

• Custom-made designs are available.

• Both Side Ultrasonic Welding for Saving Sewing Thread.

• Equipped Servo Motor for precise cutting length (±1%).

• Equipped High Quality Alloy Steel Cutter.

• Equipped Bag Mouth Anit-Stick Device.

• Punching Unit for "X" Hole and "O" Hole Punch Available.

• Custom-made designs are available.

• This Printing Press is Specially Designed for Jumbo Bag Printing.

• Equipped Ink Circulation Pump in Each Color for Manage Proper Ink Consistency.

• Patented Separation Device between Printing Roller and Conveyor Belt to Avoid Stain Conveyor During Empty Load.

• 1 to 5 Printing Press Flexibly Provided According to Customer's Demand.

• Custom-made designs are available.

• The BOTHEVEN Printing Press #MP Serial is design for fabric sheet printing, such as after cutting and bottom sewing of laminated or un-laminated bag, paper bag ....etc.

• Easy operation, easy change printing plate.

• Special design a Action Roller dispense device, the printing cylinder won't dirty conveyor when empty load.

• Equipped Servo Motor For Precise Cutting Length (± 1 mm ).

• Equipped High Quality Alloy Steel Cutter.

• Equipped Bag Mouth Anti-Stick Device.

• Auto Bag Top Alignment & Hemming of Liner Inserted PP Woven Bag.
  (Automatic Bag Top Alignment for PP Woven Bag and Inner PE Liner)

• Bag Top can be Folded or Non-Folded.

• Experiencing Clean Process of Bag Top Hemming. Largely Reducing Hand-Touching on the Bag Top Area.

• Servo Driven Gripper Type Conveying Delivery, Ensuring Neat & Steady Bag Delivery.

• Saving Manpower and Saving Cultivated Training for Skilled Manuel Operators.

• Imprint Arrangement  6+0, 5+1, 4+2, 3+3 colors combinations

• Production Output : 120 meter / min

• Based on our original Reel to Reel Printing Line which had produced more than 10 years, we have further up-grade our machine. The New Reel to Reel Printing Line is a whole new design, the main improvements we need to emphasize are:
  Equipped Gear Box on Each Printing Station, These Gear Box Can 360X Online Print Registration While the Machine in Running.
  Equipped Overhead Drying Oven.

• Gear-Box equipped on each Printing Station, which, can perform online 360 rotation, in facilitating the conduct of micro adjustment required on individual station Imprint-Artwork Registration, under Non-Stop Operation.

• Enhanced Drying Efficiency for Quickly Drying

• Multi-purpose For Laminated PP Woven Bag, Un-laminated PP Woven Bag, Kraft Paper Bag.

• Equipped Sewing Thread Broken Sensor.

• Equipped Auto-scissor For Thread Cutting.

• Finished Bad Auto-counting & Stack.

• Zigzag Type High Quality Alloy Steel Cutter

• Double-Fold sewing Guide Device

• Cold Cutting System (for laminated bag)

• Mark reading sensor (for pre-printed fabric roll)

• In-Line Gusset Device

• Perforation Needle Roller

• Reel to Reel Printing Line is the most efficient way for the PP woven bag printing, and capable of two side printing on the bag in the one process, based on the current market demand, we are able to proide 12 colors(each side 6 colors) Reel to Reel Printing Line.

• Our Reel to Reel Printing Line provide the best printing quality with high output (up to 120 meter / minute) and only one operator required. Decreasing the printing cost to the lowest. It is the most wisdom choice for printing.

• Imprint Arrangement  6+0, 5+1, 4+2, 3+3 colors combinations

• Production Output : 120 meter / min

• Based on our original Reel to Reel Printing Line which had produced more than 10 years, we have further up-grade our machine. The New Reel to Reel Printing Line is a whole new design, the main improvements we need to emphasize are:
  Equipped Gear Box on Each Printing Station, These Gear Box Can 360X Oline Print Registration While the Machine in Running.
  Equipped Overhead Drying Oven.

• Gear-Box equipped on each Printing Station, which, can perform online 360 rotation, in facilitating the conduct of micro adjustment required on individual station Imprint-Artwork Registration, under Non-Stop Operation.

• Enhanced Drying Efficiency for Quickly Drying

• Imprint Arrangement  6+0, 5+1, 4+2, 3+3 colors combinations

• Production Output : 120 meter / min

• Based on our original Reel to Reel Printing Line which had produced more than 10 years, we have further up-grade our machine. The New Reel to Reel Printing Line is a whole new design, the main improvements we need to emphasize are:
  Equipped Gear Box on Each Printing Station, These Gear Box Can 360X Online Print Registration While the Machine in Running.
  Equipped Overhead Drying Oven.

• Gear-Box equipped on each Printing Station, which, can perform online 360 rotation, in facilitating the conduct of micro adjustment required on individual station Imprint-Artwork Registration, under Non-Stop Operation.

• Enhanced Drying Efficiency for Quickly Drying

• Fully Automatic In-Line Process For Inserting-Cutting-Sewing

• Applied for both functions:
  1. Liner can be fully sewn with PP Woven Bag.
  2. Liner also can be not sewn / loose inside PP Woven Bag.

• Without inserting liner, the machine can process for normal Cutting-Sewing function.

• Saving Manpower Hugely.

• With Excellence Quality & Stable Performance.

• Equipped Servo Motors for Precise Printing Graphic and Printing Length Control

• On-line Servo Control Printing Position Registration System (with Touch Screen Operation)

• (Each printing station equipped with servo motor to adjust printing position during machine running)

• Equipped with On-line Camera Inspection (Italy made) Two Units, Monitoring Printing Quality during Machine Running.

• Equipped with Doctor Blade System and Ceramic Anilox Roller as Standard Equipment

• Tube Laminated or coated Flat Woven Fabric in order to facilitate the client's application on rear end process of bag-making.

• “Touch Screen Type” Operation Panel & Synchronized System as Standard Equipment

• Line Speed: Max 120 meter/min

• Equipped Auto Roll Changing System

• “Touch Screen Type” Operation Panel & Synchronized System as Standard Equipment

• Line Speed: Max 120 meter/min

• Equipped Auto Roll Changing System

• Fully Automatic In-Line Process For Cutting-Sewing-Bag Top Hemming with 22~25 bags/min production capacity.
  (All-in-One Process from PP Woven Rolls into Finished Bags)

• Without Bag Top Hemming, the HEMITEC can process for Normal Cutting-Sewing Function with 38~40 bags/min production capacity.

• Experiencing Clean Process of Bag Top Hemming. Largely Reducing Hand-Touching on the Bag Top Area.

• Servo Driven Gripper Type Conveying Delivery, Ensuring Neat & Steady Bag Delivery.

• Saving Manpower and Saving Cultivated Training for Skilled Manuel Operators.

• Excellent design, reliable finishing quality, complete and efficient after-sales service, will be your optimum business choice.

• Screw, T-DIE adopt high quality alloy steel with hardness treatments.

• Equip High Level Synchronized Control System and Touch Screen Operation Interface for easy-operation.

• Auto Thermo Control adopts Ceramic Heater + SCR Control

• Double Layer (Upper & Lower) Heating Oven, increase the yarn quality and meet the standard stretching yarn strength.

• Equipped with Two Servo Motors

• Equipped with 90ﾟBag Transfer Gripper

• Display Screen Operation Interface

• High Product Output (32-45 Bag / min)

• Custom-made designs are available

THIS GUSSET-CUTTING-SEWING LINE IS DESIGN TO FLAWLESSLY FORM SIDE GUSSET WITH BOTTOM FOLD & SEWN, SECTIONAL ELEMENT INCLUDING:

• Un-winding unit equipped with EPC

• Micro-Perforation unit.

• Gusset Forming unit (equipped Infrared Rays for forming quality).

• Mark sensor for printed fabric roll.

• Cutting unit equipped both cold cutter and hear cutter.

• Bottom fold & sewing unit.

• Finished bag automatic count stacker delivery unit.

• Printing Output : 32-48 bags / minute

• Reel to Reel line designed, easy for operation.

• Equipped twist device for turn printing position to the central of gusset area.

THIS LINE IS DESIGNED TO PROCESS PRODUCT FROM #GS-2002, FINISHING WITH FEEDING VALVE FORMING AND MOUTH FOLD & SEW, SECTIONAL ELEMENTS INCLUDING:

• Feeding table with optical position control.

• "L" shape cold cutting unit.

• Automatic "feeding valve" forming unit.

• Mouth fold & sewn unit.

• Automatic count stacker unit.
